HDPE Drainage Board Production Line is Junsheng's innovative machinery in China (patent protected). Under
unique mechanics design, Junsheng machine has following advantages:
● Convex wall thickness of the circular convex on the drainage panel is well-proportioned.
● Compression strength is 50% higher than similar product, which solves the problem.
● Power saving 30%.
● Higher output
● Same forming roller, with changing different dimples, different sizes will be got.
● With changing mould, round and square shape.
● Drainage board thickness range is 0.5-5.5mm, width up to 5000mm.
● Double color can be produced by another model machine.
- Size: 200-400
- Place of Origin: China
- Brand Name: Jiaxing Junsheng Machinery
- Model Number: PSB-1000,PSB2000,PSB-3000,PSB4000,PSB-5000
- Weight: 20000.000 kg
Main Technical Specification
Model | PSB-2000 | PSB-3000 | PSB-4000 | PSB-5000 | |
Screw dia. | mm | 135 | 150 | 180 | 150×2 |
L/D ratio | L/D |
| 30:1 | 30:1 | 30:1 |
Product width | mm | 2000 | 3000 | 4000 | 5000 |
Product height | mm | 8, 10, 12, 15, 18, 20, 25, 30, 35, 40 | |||
Output | Kg/h | 400 | 500 | 700 | 1000 |
Line speed | m/min | 2-6 | |||
Installed capacity | KW | 252 | 320 | 410 | 550 |
Power consumption | KW | 132 | 160 | 220 | 300 |
Dimensions (L×W×H) | m | 22×4×2.8 | 22×5×2.8 | 22×6×2.8 | 23×6×2.8 |
Total weight | T | 16 | 20 | 28 | 35 |
